在做项目的时候 遇到一个需要把页面上的一些元素一键转成图片并且可以下载，在这里就做一个简单的介绍，希望可以帮到大家！！

需要引入html2canvas.js、canvas2image.js、base64.js 点击[获取资源][Link 1]

需要在header中引入 html2canvas.js、canvas2image.js、base64.js 库文件

html2image思路   需要获取的元素的节点-->点击捕获按扭-->获取节点内元素信息-->利用库文件html2canvas进行绘制-->绘制成功后点击下载按钮-->利用库文件canvas2image转换为img，使用base64对图片编码-->下载图片

![SouthEast][]

![SouthEast 1][]

![SouthEast 2][]

![SouthEast 3][]

**html代码：**

<!DOCTYPE html>
    <html lang="en">
    <head>
    	<meta charset="UTF-8">
    	<title>html元素转canvas并一键生成png图片(支持img图片元素)</title>

    	<script src="js/html2canvas.min.js"></script>


    	<script src="js/canvas2image.js"></script>
    	<script src="js/base64.js"></script>
    	<style>
    		p{
    			font-size: 15px;
    			font-family: 'Microsoft YaHei', 'Lantinghei SC', 'Open Sans', Arial, 'Hiragino Sans GB', 'STHeiti', 'WenQuanYi Micro Hei', 'SimSun', sans-serif;
    		}
    		#content{
    			border-radius: 3px;
    		}
    		#btnSave,#Download{
    		    position: absolute;
    		    left: 180px;
    		    top: 540px;
    		    width: 78px;
    		    height: 30px;
    		    background-color: #22b4f6;
    		    color: #fff;
    		    text-align: center;
    		    border-radius: 3px;
    		    border: none;
    		}
    		#Download{
    		    margin-left: 560px;
    		}
    		.tx,.bt{
    			border: 1px solid #999;
    			width: 100px;
    			height: 20px;
    			border-radius: 3px;
    		}
    		.bt{
    			background-color: #22b4f6;
    			color: #fff;
    			text-align: center;
    			border: none;
    		}
    	</style>
    </head>
    <body>
    <div>注意：html2canvas 只能在服务器中抓取img</div>
    	<div id="content" style="width:500px;height:500px;border:1px solid #22b4f6;float:left;text-align:center; background: #fff;">
    		<p><img width="80" height="100" src="images/pic.jpg" alt="头像"></p>
    	    <p>昵称：马云云</p>
    	    <p>技能：前端 + 后端 + 小程序 + webapp</p>
    	    <p>语言：html5、php、mysql</p>
    	    <p>脚本：javascript</p>
    	    <p>框架：vue.js、smarty、thinkphp、MUI、WeUI、Bootstrap</p>
    	    <p><input type="text" class="tx" placeholder="微信公众号开发"></p>
    	    <p><input type="button" class="bt" value="网站微站开发"></p>
    	</div>
    	<div style="width:60px;height:302px;float:left;text-align:center;line-height:302px;font-size:30px;color:#22b4f6;">==></div>
    	<div id="images" style="width:190px;height:302px;float:left;text-align:center;line-height:302px">图片预览区</div>
    	<button id="btnSave">抓取图片</button><button id="Download">下载图片</button>
    </body>
    <script>
    /*生成canvas图形*/

    // 获取按钮id
    var btnSave = document.getElementById("btnSave");
    // 获取内容id
    var content = document.getElementById("content");
    // 进行canvas生成
    btnSave.onclick = function(){
    	html2canvas(content, {
            onrendered: function(canvas) {
            	//添加属性
            	canvas.setAttribute('id','thecanvas');
    			//读取属性值
    			// var value= canvas.getAttribute('id');
                document.getElementById('images').innerHTML = '';
                document.getElementById('images').appendChild(canvas);
            }
    	});
    }
    </script>
    <script>
    /*
     * 说明
     * 不支持跨域图片
     * 不能在浏览器插件中使用
     * 部分浏览器上不支持SVG图片
     * 不支持Flash
     */
    var Download = document.getElementById("Download");
    Download.onclick = function(){
    	var oCanvas = document.getElementById("thecanvas");

    	/*自动保存为png*/
    	// 获取图片资源
    	var img_data1 = Canvas2Image.saveAsPNG(oCanvas, true).getAttribute('src');
    	saveFile(img_data1, 'richer.png');


    	/*下面的为原生的保存，不带格式名*/
    	// 这将会提示用户保存PNG图片
    	// Canvas2Image.saveAsPNG(oCanvas);
    }
    // 保存文件函数
    var saveFile = function(data, filename){
        var save_link = document.createElementNS('http://www.w3.org/1999/xhtml', 'a');
        save_link.href = data;
        save_link.download = filename;

        var event = document.createEvent('MouseEvents');
        event.initMouseEvent('click', true, false, window, 0, 0, 0, 0, 0, false, false, false, false, 0, null);
        save_link.dispatchEvent(event);
    };
    </script>
    </html>

**html2canvas.min.js 源代码：（复制可用）**

/*
      html2canvas 0.4.1 <http://html2canvas.hertzen.com>
      Copyright (c) 2013 Niklas von Hertzen

      Released under MIT License
    */

canvas2image.js 库文件源代码：（复制可用）

/*
     * Canvas2Image v0.1
     * Copyright (c) 2008 Jacob Seidelin, jseidelin@nihilogic.dk
     * MIT License [http://www.opensource.org/licenses/mit-license.php]
     */

    var Canvas2Image = (function() {

    	// check if we have canvas support
    	var bHasCanvas = false;
    	var oCanvas = document.createElement("canvas");
    	if (oCanvas.getContext("2d")) {
    		bHasCanvas = true;
    	}

    	// no canvas, bail out.
    	if (!bHasCanvas) {
    		return {
    			saveAsBMP : function(){},
    			saveAsPNG : function(){},
    			saveAsJPEG : function(){}
    		}
    	}

    	var bHasImageData = !!(oCanvas.getContext("2d").getImageData);
    	var bHasDataURL = !!(oCanvas.toDataURL);
    	var bHasBase64 = !!(window.btoa);

    	var strDownloadMime = "image/octet-stream";

    	// ok, we're good
    	var readCanvasData = function(oCanvas) {
    		var iWidth = parseInt(oCanvas.width);
    		var iHeight = parseInt(oCanvas.height);
    		return oCanvas.getContext("2d").getImageData(0,0,iWidth,iHeight);
    	}

    	// base64 encodes either a string or an array of charcodes
    	var encodeData = function(data) {
    		var strData = "";
    		if (typeof data == "string") {
    			strData = data;
    		} else {
    			var aData = data;
    			for (var i=0;i<aData.length;i++) {
    				strData += String.fromCharCode(aData[i]);
    			}
    		}
    		return btoa(strData);
    	}

    	// creates a base64 encoded string containing BMP data
    	// takes an imagedata object as argument
    	var createBMP = function(oData) {
    		var aHeader = [];

    		var iWidth = oData.width;
    		var iHeight = oData.height;

    		aHeader.push(0x42); // magic 1
    		aHeader.push(0x4D);

    		var iFileSize = iWidth*iHeight*3 + 54; // total header size = 54 bytes
    		aHeader.push(iFileSize % 256); iFileSize = Math.floor(iFileSize / 256);
    		aHeader.push(iFileSize % 256); iFileSize = Math.floor(iFileSize / 256);
    		aHeader.push(iFileSize % 256); iFileSize = Math.floor(iFileSize / 256);
    		aHeader.push(iFileSize % 256);

    		aHeader.push(0); // reserved
    		aHeader.push(0);
    		aHeader.push(0); // reserved
    		aHeader.push(0);

    		aHeader.push(54); // dataoffset
    		aHeader.push(0);
    		aHeader.push(0);
    		aHeader.push(0);

    		var aInfoHeader = [];
    		aInfoHeader.push(40); // info header size
    		aInfoHeader.push(0);
    		aInfoHeader.push(0);
    		aInfoHeader.push(0);

    		var iImageWidth = iWidth;
    		aInfoHeader.push(iImageWidth % 256); iImageWidth = Math.floor(iImageWidth / 256);
    		aInfoHeader.push(iImageWidth % 256); iImageWidth = Math.floor(iImageWidth / 256);
    		aInfoHeader.push(iImageWidth % 256); iImageWidth = Math.floor(iImageWidth / 256);
    		aInfoHeader.push(iImageWidth % 256);

    		var iImageHeight = iHeight;
    		aInfoHeader.push(iImageHeight % 256); iImageHeight = Math.floor(iImageHeight / 256);
    		aInfoHeader.push(iImageHeight % 256); iImageHeight = Math.floor(iImageHeight / 256);
    		aInfoHeader.push(iImageHeight % 256); iImageHeight = Math.floor(iImageHeight / 256);
    		aInfoHeader.push(iImageHeight % 256);

    		aInfoHeader.push(1); // num of planes
    		aInfoHeader.push(0);

    		aInfoHeader.push(24); // num of bits per pixel
    		aInfoHeader.push(0);

    		aInfoHeader.push(0); // compression = none
    		aInfoHeader.push(0);
    		aInfoHeader.push(0);
    		aInfoHeader.push(0);

    		var iDataSize = iWidth*iHeight*3;
    		aInfoHeader.push(iDataSize % 256); iDataSize = Math.floor(iDataSize / 256);
    		aInfoHeader.push(iDataSize % 256); iDataSize = Math.floor(iDataSize / 256);
    		aInfoHeader.push(iDataSize % 256); iDataSize = Math.floor(iDataSize / 256);
    		aInfoHeader.push(iDataSize % 256);

    		for (var i=0;i<16;i++) {
    			aInfoHeader.push(0);	// these bytes not used
    		}

    		var iPadding = (4 - ((iWidth * 3) % 4)) % 4;

    		var aImgData = oData.data;

    		var strPixelData = "";
    		var y = iHeight;
    		do {
    			var iOffsetY = iWidth*(y-1)*4;
    			var strPixelRow = "";
    			for (var x=0;x<iWidth;x++) {
    				var iOffsetX = 4*x;

    				strPixelRow += String.fromCharCode(aImgData[iOffsetY+iOffsetX+2]);
    				strPixelRow += String.fromCharCode(aImgData[iOffsetY+iOffsetX+1]);
    				strPixelRow += String.fromCharCode(aImgData[iOffsetY+iOffsetX]);
    			}
    			for (var c=0;c<iPadding;c++) {
    				strPixelRow += String.fromCharCode(0);
    			}
    			strPixelData += strPixelRow;
    		} while (--y);

    		var strEncoded = encodeData(aHeader.concat(aInfoHeader)) + encodeData(strPixelData);

    		return strEncoded;
    	}


    	// sends the generated file to the client
    	var saveFile = function(strData) {
    		document.location.href = strData;
    	}

    	var makeDataURI = function(strData, strMime) {
    		return "data:" + strMime + ";base64," + strData;
    	}

    	// generates a <img> object containing the imagedata
    	var makeImageObject = function(strSource) {
    		var oImgElement = document.createElement("img");
    		oImgElement.src = strSource;
    		return oImgElement;
    	}

    	var scaleCanvas = function(oCanvas, iWidth, iHeight) {
    		if (iWidth && iHeight) {
    			var oSaveCanvas = document.createElement("canvas");
    			oSaveCanvas.width = iWidth;
    			oSaveCanvas.height = iHeight;
    			oSaveCanvas.style.width = iWidth+"px";
    			oSaveCanvas.style.height = iHeight+"px";

    			var oSaveCtx = oSaveCanvas.getContext("2d");

    			oSaveCtx.drawImage(oCanvas, 0, 0, oCanvas.width, oCanvas.height, 0, 0, iWidth, iHeight);
    			return oSaveCanvas;
    		}
    		return oCanvas;
    	}

    	return {

    		saveAsPNG : function(oCanvas, bReturnImg, iWidth, iHeight) {
    			if (!bHasDataURL) {
    				return false;
    			}
    			var oScaledCanvas = scaleCanvas(oCanvas, iWidth, iHeight);
    			var strData = oScaledCanvas.toDataURL("image/png");
    			if (bReturnImg) {
    				return makeImageObject(strData);
    			} else {
    				saveFile(strData.replace("image/png", strDownloadMime));
    			}
    			return true;
    		},

    		saveAsJPEG : function(oCanvas, bReturnImg, iWidth, iHeight) {
    			if (!bHasDataURL) {
    				return false;
    			}

    			var oScaledCanvas = scaleCanvas(oCanvas, iWidth, iHeight);
    			var strMime = "image/jpeg";
    			var strData = oScaledCanvas.toDataURL(strMime);

    			// check if browser actually supports jpeg by looking for the mime type in the data uri.
    			// if not, return false
    			if (strData.indexOf(strMime) != 5) {
    				return false;
    			}

    			if (bReturnImg) {
    				return makeImageObject(strData);
    			} else {
    				saveFile(strData.replace(strMime, strDownloadMime));
    			}
    			return true;
    		},

    		saveAsBMP : function(oCanvas, bReturnImg, iWidth, iHeight) {
    			if (!(bHasImageData && bHasBase64)) {
    				return false;
    			}

    			var oScaledCanvas = scaleCanvas(oCanvas, iWidth, iHeight);

    			var oData = readCanvasData(oScaledCanvas);
    			var strImgData = createBMP(oData);
    			if (bReturnImg) {
    				return makeImageObject(makeDataURI(strImgData, "image/bmp"));
    			} else {
    				saveFile(makeDataURI(strImgData, strDownloadMime));
    			}
    			return true;
    		}
    	};

    })();

**base64.js 库文件源代码：（复制可用）**

/* Copyright (C) 1999 Masanao Izumo <iz@onicos.co.jp>
     * Version: 1.0
     * LastModified: Dec 25 1999
     * This library is free.  You can redistribute it and/or modify it.
     */

    /*
     * Interfaces:
     * b64 = base64encode(data);
     * data = base64decode(b64);
     */

    (function() {

    var base64EncodeChars = "ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/";
    var base64DecodeChars = new Array(
        -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1,
        -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1,
        -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, -1, 62, -1, -1, -1, 63,
        52, 53, 54, 55, 56, 57, 58, 59, 60, 61, -1, -1, -1, -1, -1, -1,
        -1,  0,  1,  2,  3,  4,  5,  6,  7,  8,  9, 10, 11, 12, 13, 14,
        15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, -1, -1, -1, -1, -1,
        -1, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40,
        41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, -1, -1, -1, -1, -1);

    function base64encode(str) {
        var out, i, len;
        var c1, c2, c3;

        len = str.length;
        i = 0;
        out = "";
        while(i < len) {
    	c1 = str.charCodeAt(i++) & 0xff;
    	if(i == len)
    	{
    	    out += base64EncodeChars.charAt(c1 >> 2);
    	    out += base64EncodeChars.charAt((c1 & 0x3) << 4);
    	    out += "==";
    	    break;
    	}
    	c2 = str.charCodeAt(i++);
    	if(i == len)
    	{
    	    out += base64EncodeChars.charAt(c1 >> 2);
    	    out += base64EncodeChars.charAt(((c1 & 0x3)<< 4) | ((c2 & 0xF0) >> 4));
    	    out += base64EncodeChars.charAt((c2 & 0xF) << 2);
    	    out += "=";
    	    break;
    	}
    	c3 = str.charCodeAt(i++);
    	out += base64EncodeChars.charAt(c1 >> 2);
    	out += base64EncodeChars.charAt(((c1 & 0x3)<< 4) | ((c2 & 0xF0) >> 4));
    	out += base64EncodeChars.charAt(((c2 & 0xF) << 2) | ((c3 & 0xC0) >>6));
    	out += base64EncodeChars.charAt(c3 & 0x3F);
        }
        return out;
    }

    function base64decode(str) {
        var c1, c2, c3, c4;
        var i, len, out;

        len = str.length;
        i = 0;
        out = "";
        while(i < len) {
    	/* c1 */
    	do {
    	    c1 = base64DecodeChars[str.charCodeAt(i++) & 0xff];
    	} while(i < len && c1 == -1);
    	if(c1 == -1)
    	    break;

    	/* c2 */
    	do {
    	    c2 = base64DecodeChars[str.charCodeAt(i++) & 0xff];
    	} while(i < len && c2 == -1);
    	if(c2 == -1)
    	    break;

    	out += String.fromCharCode((c1 << 2) | ((c2 & 0x30) >> 4));

    	/* c3 */
    	do {
    	    c3 = str.charCodeAt(i++) & 0xff;
    	    if(c3 == 61)
    		return out;
    	    c3 = base64DecodeChars[c3];
    	} while(i < len && c3 == -1);
    	if(c3 == -1)
    	    break;

    	out += String.fromCharCode(((c2 & 0XF) << 4) | ((c3 & 0x3C) >> 2));

    	/* c4 */
    	do {
    	    c4 = str.charCodeAt(i++) & 0xff;
    	    if(c4 == 61)
    		return out;
    	    c4 = base64DecodeChars[c4];
    	} while(i < len && c4 == -1);
    	if(c4 == -1)
    	    break;
    	out += String.fromCharCode(((c3 & 0x03) << 6) | c4);
        }
        return out;
    }

    if (!window.btoa) window.btoa = base64encode;
    if (!window.atob) window.atob = base64decode;

    })();

**备注：   html2canvas 只能在服务器中抓取img，**

** 如果是在本地编辑文件在浏览器** **上可以抓取除了img标签外的元素，**

** 但是节点中的img是抓取不到的**

** 必须将代码放在服务器中进行对img标签进行抓取**

[Link 1]: https://pan.baidu.com/s/1nw4nHRr
[SouthEast]: /images/20220601/2d5d2b0dbfa04f2e94b864b3f320a26b.png
[SouthEast 1]: /images/20220601/464978d1567243fe8fe59138a57aa49c.png
[SouthEast 2]: /images/20220601/e6a7cee78be94136939bbd0e7e993ace.png
[SouthEast 3]: /images/20220601/e44ed86abb724868ba148fefc698d875.png
