Iocomp Components Release Notes-Ω578867473
Release: .Net WinForms V5 SP3
Release Date: 21 September 2020
This document is organized into the following sections…
Latest News
Revision History
Installation Notes
Latest News
The .Net WinForm V5 SP3 is now available for download.
Revision History
NET WinForms [Version 5.0 SP3]
New Features:
Added support for VS2019 (Toolbox and Help integration).
Bug Fixes:
None.
NET WinForms [Version 5.0 SP2]
New Features:
Added support for VS2017 (Toolbox and Help integration).
Bug Fixes:
None.
NET WinForms [Version 5.0 SP1]
New Features:
Upgraded PlotDataCursorChannel to support pointer movement using the Left & Right keyboard arrow keys. When the data-cursor is configued for the Peroid or Frequency style, hold the CTRL key down to move second pointer (Pointer2).
Added HideHintOnDrag property to the PlotDataCursorChannel object. Useful when you have the SnapToDataPoint option enabled, and you do not wish to display interpolated values when dragging the data-cursor to a new data-point.
Added MarginLeft, MarginRight, MarginTop, and MarginBottom properties to the BorderControl class. The BorderControl class is used by all visual Iocomp controls. The legacy Margin property is applied to all sides of the control equally and it is added to the MarginXXX property of a specific side (Ex. Margin =5 & MarginLeft = 3 results in a margin-left total of 8 pixels).
Added ExponentShort style to TextFormatDoubleAll class. This class is used by the Plot control and various scale based gauge controls. Allows for a shorter formatting of the exponent text by removing unnecessary 0’s in the exponent power (Ex. 5.0e+2 vs 5.0e+002).
Bug Fixes:
Fixed Property-Editor opening issue. The issue would display an error dialog … “Unable to load one or more of the requested types” (Note: Final Fix. Previous fix only solved about half of the issues).
Fixed Plot control Legend layout issue. When the legend was placed at the bottom of the data-view, depending on how it was configured, would result in unnecessary spacing being added to the bottom. In some cases, a large amount of white-space was reserved.
NET WinForms [Version 5.0 SP0]
New Features:
Added support for VS2015 (Toolbox and Help integration). Iocomp 4.5 assemblies are fully compatible with the (4.5.1), (4.5.2), and (4.6) application targets.
Add DoSnapToPoint method to PlotDataCursorBase object. Calling this method will cause the data-cursor to snap to the nearest data-point regardless of the SnapToPoint property setting (Note: For the XY data-cursor type, this method call will result in no action being taken).
Added TitleColorStyle property to PlotLegendBasic. (TitleColorStyle supports 4 options : ForeColor, ChannelColor, XAxisColor, YAxisColor).
Added MarkersTurnOffLimit property to the channel types listed below. A setting of 0 turns off this feature. When the number of displayed data-markers exceeds this property settings, the markers will not be drawn to improve drawing performance. This feature is typically used when a large number of data-points are shown in the data-view and the shear number of markers drawn provides no useful information to the end-user. As the data-view is zoomed in, and the number of data-points drawn is reduced, and the markers will reappear.
Trace
TraceXY
Sweep-Interval
Rational
Polynomial
Fill
Digital
Differential
Cubic-Spline
Bi-Fill
Added StepSizeStyle, StepSizeArrow, StepSizePage, and StepSizeWheel properties to the Knob control. The StepSizeStyle property can be set to Value or Percent (default = Percent). The StepSizeArrow property controls the step size increment for the Left, Right, Up, and Down arrow keys. The StepSizePage property controls the step size increment for the Page-Up and Page-Down keys. The StepSizeWheel property controls the step size increment for the Mouse-Wheel.
Added StepSizeStyle, StepSizeArrow, StepSizePage, and StepSizeWheel properties to the Slider control. The StepSizeStyle property can be set to Value or Percent (default = Percent). The StepSizeArrow property controls the step size increment for the Left, Right, Up, and Down arrow keys. The StepSizePage property controls the step size increment for the Page-Up and Page-Down keys. The StepSizeWheel property controls the step size increment for the Mouse-Wheel.
Added StepSizeArrow, StepSizePage, and StepSizeWheel properties to the SwitchSlider control. The StepSizeArrow property controls the step size increment for the Left, Right, Up, and Down arrow keys. The StepSizePage property controls the step size increment for the Page-Up and Page-Down keys. The StepSizeWheel property controls the step size increment for the mouse-wheel.
Added StepSizeArrow, StepSizePage, and StepSizeWheel properties to the SwitchRotary control. The StepSizeArrow property controls the step size increment for the Left, Right, Up, and Down arrow keys. The StepSizePage property controls the step size increment for the Page-Up and Page-Down keys. The StepSizeWheel property controls the step size increment for the mouse-wheel.
Removed restriction on plot sub-objects which prevented mouse-right events when the ContextMenuEnabled property was set to False.
Updated Data-Cursor mouse-moving behavior when the axis is configured for logarithmic-mode. Data-Cursor pointer now tracks with the O/S mouse-cursor pointer. Previously, would move in progressively larger increments as the scale grew in total span.
Updated Axes logarithmic-mode scroll behavior when moved with the Mouse-wheel. Now moves in 1% increments per wheel-click, regardless of the scale range displayed. Previously, would move in progressively larger increments as the scale grew in total span.
Bug Fixes:
Fixed linear scale tick generation issue. Would occur with span settings below one. Would result in ticks being drawn outside of the scale range.
Fixed Limit-Line User-Can-Move issue. Would only occur when the scale was Log10 based. Would result in the Limit-Line jumping outside of the visible graphing area if dragged significantly.
Fixed Axes scale-generator oscillation Issues. Major Ticks displayed on the axes would toggle between a larger and smaller amount as the axes were scrolled or zoomed resulting in an Oscillation effect.
Fixed Property-Editor opening issue. Would show a dialog with the following text… “Unable to load one or more of the requested types”.
Fixed data-view right-most and bottom-most pixel clipping issue. Would only occur if the object would touch the right-most or bottom-most pixel of the data-view edge. All intersecting pixels along the edge (1-pixel thickness) would not be drawn.
